Total DFT
500-3000 microns (fire rating dependent)
Service Life
Design life of structure
Environment
Interior and exterior (with topcoat for exterior)
Layers
3 coat system
FireSeal intumescent fire-retardant coating providing passive fire protection for structural steel. Expands 40-50 times when exposed to fire, forming an insulating carbon char layer that protects steel from reaching critical temperature.
Coating System — Layer by Layer
1
PrimerAnti-corrosive primer
Epoxy Zinc Phosphate Primer
Corrosion protection base compatible with intumescent
DFT: 35-50 microns
Coats: 1
Airless spray
2
IntumescentIntumescent
FireSeal Intumescent Fire-Retardant Coating
Expands 40-50x in fire. Forms insulating char. Up to 120-min fire rating.
DFT: 500-3000 microns
Coats: Multiple
Airless spray
3
Topcoat (exterior)Aliphatic PU
Aliphatic Polyurethane Topcoat
Weather protection for intumescent in exterior applications
DFT: 50 microns
Coats: 1
Airless spray
Surface Preparation
- Blast cleaning to Sa 2.5
- Apply compatible anti-corrosive primer first
- Surface must be dry and free from contamination
Applicable Standards
BS 476IS 15509ASTM E119EN 13381IS 17044-2018UL 263
Applications
- I-beams and columns
- Trusses and purlins
- Oil and gas facilities
- Commercial buildings
- Data centres
- Airport structures
- Industrial warehouses
Why Anupam Paints
- 120-minute fire rating tested
- Salt spray resistance 1000+ hours
- Conforms to IS 17044-2018, ASTM E119, UL 263
- Advanced carbon nano-structured technology
Need This Coating System?
Our technical team will prepare a detailed specification and competitive quotation for your project.
